QUAD SERIES
INCLUDED IN THE KIT:
Quad® head unit with nylon headstrap, rubber
hard hat strap and 3M Dual Lock™
: MADE IN
iUSA
QUAD II
INTRINSICALLYSAFE
The second inour series of Intrinsically Safe headlamps, the Quad II provides unparalleled design and performance. The
Quad II shares the same basic design principals as the original and proven Quad but takes it up to a UL Cll Div. 1 rating. The
fundamental lighting characteristic of the Quad provides a vast amount of area light for all purpose needs and performing
up -close tasks. The light beam is smooth and wide allowing you towork with your hands without glare or reflection. With its
robust construction, superior materials, and waterproof design, the Quad II is suited for any environment.
SPECS
POWER
78 Lumens
LAMP
4 Ultrabright LEDs
(regulated)
BURN TIME
105 Hours
BATTERIES
3 AAA Alkaline
(Included)
WEIGHT
3.4oz/96g
UL RATING
Class 1 Division 1
Groups A, B, C & 0
UL TEMP CODE
T4
WATERPROOF
IPX7
(1 meter)
TECHNOLOGY
PERFORMANCE
LUMENS
H
4 LED
2 Modes
HIGH
LOW
BLACK
PN: QUAD-II
©Time
T. = Total Run Time / R. = Regulated Run Time
R. 1 h, T. 105h
R. 5h,T.110h
DISTANCE (m)
D
30
50
QUAD'
INDUSTRIAL
At a mere 96 grams, the Quad is the lightest inPrinceton Tec's line of regulated-LED headlamps. 4 Ultrabright LEDs power through the
darkest conditions. TheLEDs are safe forever inside a tough waterproof housing that will survive severe Impacts and water submersions
up to 1 meter. Weight conscious users will appreciate the Quad's sophisticated circuitry that allows the use of lithium AAA batteries. They
reduce the Quad's weight to 82grams, perform in extremely cold temperatures, and significantly increase regulated burn times on all modes.
Equipped with regulated LEDs that maintain constant brightness and a battery power meter, this light just may be smarter than you are.
SPECS
TECHNOLOGY
POWER
LAMP
BURN TIME
BATTERIES
WEIGHT
UL RATING
UL TEMP CODE
WATERPROOF
PERFORMANCE
78 Lumens
4 Ultrabright LEDs
(regulated)
108 Hours
3 AAA Alkaline
(included)
or Lithium
3.4oz / 96g
Class I Division 2
Groups A, B, C & D
Class II Division 2 Groups F & G
T6
IPX7
(1 meter)
un
c 0 «
ALKALINE M
LITHIUM
3 AAA • COMPATIBLE
4 Modes
HIGH
FLASH
MEDIUM
LOW
©Time
T. = Total Run Time / R. = Regulated Run Time
R. 1h,T.80h
R.12h,T.150h
R. 5h, T. 92h
R. 10h, T. 108h
BLACK PN: QUAD-IND
DISTANCE (m)
0
PRINCETON TEC
