BATTERY POWER METER
The battery power meter provides continuous feedback on the condition
[j
of the batteries, indicating high, medium or low battery life. This informa-
BPM
tion allows you to make educated decisions about changing batteries or
packing a spare set.
360° LIGHT
^r*£*i_
This light is designed for area illumination,and disperses light in a 360 degree
"^T"V^ pattern to light up a campsite orother area.
360° LIGHT
BEAM DISTANCE
Princeton Tec measures beam distance as the distance from the light source at
which the light emitted is greater than 0.25 lumens, an amount of light which is
similar to the amount of light that is cast by a full moon on a clear night.
BEAM PATTERNS
FOCUSED NARROW BEAMS
This pattern creates a long, powerful beam of light excellent for illumi¬
nating distant areas, or for use during fast paced activities.
HALOGEN INCANDESCENT BULBS
_
work in exactly the same way as traditional incandescent bulbs found
" F
1
" '
jn your home, with one major difference: they contain halogen gas
HALOGEN
instead of nitrogen orargon. This difference allows the bulb to burn
brighter, more efficiently, and for longer periods of time. The bulb
needs to be replaced less frequently since filament life is extended.
XENON INCANDESCENT BULBS
come closest to replicating the color temperature of daytime light. They
'
also generate about twice the brightness and consume about half the
XENON
p
0 w e r 0
f traditional halogen bulbs. Xenon lights are well-suited to appli–
cations where a long-throwing beam is required.
FOCUSED WIDE BEAM
This beam pattern isan excellent choice for multipurpose activities.At
close range, wide beams simulate normal daylight conditions and allow
you to take advantage of your peripheral vision.
WEIGHT
Princeton Tec's advertised product weights always include batteries.For
many products, battery weight is a large percentage ofoverall weight.
Weight can be significantly reduced by using lithium batteries in lithi–
um-compatible products.
UL CERTIFICATION
©
Underwriters Laboratories Inc. (UL) is an independent, not-for-profit
u
product-safety testing and certification organization. They have been
testing products for public safety for more than a century. Inorder fora
product to bear the certified UL Mark, itmust pass all UL requirements at
their testing facility.
MULTIPLE MODE
Multiple settings on many ofour products give you the flexibility to adjust
your light's brightness to illuminate greater distances or to conserve
battery power, depending on your needs.
MULTIPLE BEAM
This beam pattern combines focused narrow and wide beams to allow
for the most versatility. At close range, the wide beams simulate normal
daylight conditions so you can take advantage of your peripheral vision,
while focused narrow beams provide distance illumination.
Princeton Tec lights that are UL certified fall into one of the following classifica–
tions: Class I - Division II - Groups A, B, C, &D, Class II - Division II - Groups F, &
G, orClass
I
- Division I - Grdups A, B, C,&D. Refer to the comparison .chart in the
rear of the, catalog. Class
I
- Division II - Groups A,B,C,& D will benoted with one
{+) Class II - Division II - approved for Groups F, & G, will be noted with two (++) -
Class
I
- Division I Approved for groups A, B, C & D will benoted with three (+++}
BURN TIME/LIGHT DURATION
'
Burntime is the time frorrUhe initial light output using fresh batteries, until the
light output reaches .25 lux. This testing procedure is commonly referred to as the
"Moonlight Standard,""which was agreed upon by several headlamp rrianufacturers
around 2002.
